Haldex Rotary Gear Flow Divider D Series Model 1300352 FD1660021 USA

DeskripsiJual Haldex Rotary Gear Flow Divider D Series Model 1300352 FD1660021 USA – Jakarta, IndonesiaBrand: HaldexBrand Origin: USAModel: 1300352Part Number: FD1660021Alternative: VH001-00480Disp. (cc/rev): 13.32Rec. Min. Flow (lpm): 26.5Rec. Max. Flow (lpm): 52.9Max. Press. (bar): 207Cont AP Between Sections bar: 83Rotary flow dividers provide many useful functions from a single pump source:– Synchronised operation of multiple cylinders or fluid motors.– Proportional division of pump output among several circuits.– Intensified flow pressure when pressure higher than pump capacity is needed.In a rotary flow divider, horsepower-in is equal to horsepower-out with very small efficiency losses. Consequently it does not generate heat. The rotary gear flow divider consists of 2 or more gear sections connected by a common shaft. Using a common inlet port, each section has its own outlet port. Because the gear sections are connected by a common shaft, the rotation speed is the same for each gear and the flow division is exactly proportional to the displacement of each of the sections.Pressure intensification is a phenomenon that is inherent in all flow divider circuits. Whenever the pressure requirement in a section is greater than another section, the pressure differential between the sections will appear in the higher pressure section as an additive to the inlet pressure. For this reason a system relief valve should be used on the inlet side.The gears are unrestricted in the direction they turn, therefore flow dividers can be used to combine the separate flows into a single flow which is equal to the sum of the various inputs.
