Audio-Technica ATW-3255DF2 Features:Durable wireless in-ear monitor system delivers high-quality sound and stable RFIdeal for use in houses of worship and performance venuesOptimized internal digital signal processing provides exceptional stereo separationWide UHF tuning bandwidth of 138 MHz for maximum versatility in an increasingly congested RF environment; available in frequency band DF2 (470 – 608 MHz)Shares design elements with the 3000 Series UHF Wireless Systems for easy integration and compatibilityTransmitter and receiver include OLED screens for optimal readout of key settings and alertsOffers network monitoring and control via Wireless Manager softwareA channel plan can be deployed to all network-connected transmitters via an RF scan from a single receiver, with no interference or third-order intermodulationBody-pack receiver operates continuously for up to 7 hours when powered by NiMH batteries and charged in the ATW-CHG3 or ATW-CHG3N charging station (sold separately)Stereo or mono operation with pan/personal mix controlsReceiver is equipped with an efficient headphone amp to ensure clear, natural sound qualityCustom audio settings include EQ, limiter, gain control and balanceReceiver’s antenna diversity improves RF stabilityIncluded ATH-E40 professional in-ear monitor headphones feature propriety dual phase push-pull drivers for exceptional accuracy and clarityTransmitter is equipped with balanced XLR inputs and loop output, plus network portAudio-Technica ATW-3255DF2 Specifications:Overall SystemOperating Frequencies: Band DF2: 470.125 to 607.875 MHzPlease note that some frequency bands might not be available in your territory or could come with a limited tuning bandwidth/transmitting power due to local regulations.Minimum Frequency Step: 25 kHzModulation Mode: FMNominal/Peak Deviation: ±34 kHz nominal / ±45 kHz peakFrequency Response: 40 Hz to 14,100 HzStereo Separation: 75 dBOperating Range: 90 m (300′), Open range environment with no interfering signalsDynamic Range: >90 dB, A-weighted, typicalTotal Harmonic Distortion:Maximum Simultaneous Use (recommended): 49 ch per bandFor assistance with multi-band operation or other frequency coordination issues, contact your local Audio-Technica dealer.Notes: For product improvement, the product is subject to modification without notice.IEM TransmitterRF Output Power: High: 50 mW, Low: 10 mW (switchable) at 50 ohms, May differ depending on the country or region in which you live.Input Connection: XLR-F type×2, (Pin1: GND, Pin2: Hot, Pin3: Cold)Maximum Input Level: XLR-F type: 24 dBu (at 0 dB sensitivity)Output Connection: 6.3 mm (1/4″) TRS×2(Tip: Hot, Ring: Cold, Sleeve: Ground）Network: 100BASE-TNetwork Port: RJ-45Power Supply: 100 to 240 V AC (50/60 Hz) to 12V DC 1 A (center positive) switched mode external power supplyAntenna Output: BNC-type, 50 ohmsDimensions: 210 mm (8.3″)×191 mm (7.5″)×43.4 mm (1.7″) (W×D×H)Weight: 1,100 g (39 oz)(without accessories)Included AccessoriesAC adapterRack-mount (large, small)Flexible UHF antennaReceiverReceiving System: Antenna diversity, Audio output cable performs as a secondary antenna to ensure stable RF performance.Image Rejection: >80 dB, typicalRF Sensitivity: 20 dBuV at 60 dBA S/N ratio (50 ohms termination)Headphone Output Jack: 3.5 mm (1/8″) TRS stereo mini-jackHeadphone Output: 40 mW (at 12 ohms)EQLow: 80 Hz / 160 Hz / 320 Hz / ±9 dB in 3 dB stepHigh: 6 kHz / 8 kHz / 10 kHz / ±9 dB in 3 dB stepLimiter: Selectable: -30dB to OFF (0 dB) in 6 dB stepsAntenna Input: SMA type, 50 ohmsOperating Temperature Range: -5℃ to 45℃ (23℉ to 113℉), Battery performance may be reduced at very low temperatures.Dimensions: 64 mm (2.5″)×23 mm (0.91″)×82 mm (3.2″) (W×D×H)Weight: 102 g (3.6 oz) (without batteries)Accessories Included: ATH-E40Battery Current/Life: 4 to 6 hours (alkaline); 5 to 7 hours (Ni-MH, 1900 mAh); 11 to 13 hours (Lithium)Depending on battery type, usage, volume level and environmental conditions.Battery Type: 3 V DC (two 1.5 V AA) (not included)
